| Line Up | HD-SDI Universal | |||
|---|---|---|---|---|
| Series | Lite | |||
| Model No. | MX3-16u | MX3-08u | MX3-04u | |
| System | OS | Embedded Linux | ||
| Language | Chinese, Chinese(S), Dutch, English, French, German, Hebrew, Hungari, Italian, Japanese, Korean, Latvian, Persian, Polish, Portuguese, Russian, Spanish, Sweden, Turkish, Arabic | |||
| Time Accuracy | 5ppm (12.5sec/month) | |||
| Time Sync. | NTP, GMT, DST | |||
| User | 15 Users (Admin., User1 ~ User14) | |||
| Access | Front button, Mouse, Remocon, Network, Key controller | |||
| Hexaplex | Live monitoring, Recording, Playback, Backup, Network, Setup | |||
| Upgrade | USB2.0 Memory stick, Network | |||
| Video | System | NTSC / PAL - Config switch | ||
| Input | 16 BNC | 8 BNC | 4 BNC | |
| Output Interface | 1 HDMI, 1 VGA | |||
| Spot | 1 BNC | |||
| Audio | Input Interface | 16 RCA | 8 RCA | 4 RCA |
| Output Interface | 1 HDMI, 1 RCA | |||
| Video Recording |
Compression | H.264 | ||
| Speed | 1920 x 1080p Real time recording (480fps / 240fps/ 120fps) | |||
| Resolution | 1080p, 720p, 960H, D1, CIF | |||
| Mode | Schedule | |||
| Event | Sensor, Motion, Audio, Text | |||
| Bit Rate | 512Kbps ~ 5Mbps/ch, Adjustable | |||
| Audeo Recording |
Compression | G.711u | ||
| Audio Sampling Rate | 8KHz | |||
| Audio Bit Rate | 64 Kbps | |||
| Playbacka | Search | Go to first rec. time, Go to last rec. time, Go to last search time, Calenda, Log viewer, Smart search, Multi-time & day search, Event search |
||
| Mode | Event only playback, Backward, Pause, Frame by frame, Speed up (x1 ~ x32, x300) |
|||
| Network | Interface | Ethernet 10/100/1G | ||
| Compression | H.264 or JPEG | |||
| Speed | Max. 720P 10fps/ch | |||
| Resolution | Max. 1280x720p | |||
| Backup | Interface | USB2.0, Network | ||
| Format | Video clip (Backup viewer), JPEG Still Image Log list, Setup data |
|||
| Booting | Live | 16sec | ||
| Recording | 40sec | |||
| Alarm | Post-Alarm | 5sec~5min | ||
| Motion Grid | 32 x 24 (NTSC/PAL) | |||
| Alarm Action | E-mail, Event Popup, Buzzer, Relay, PTZ Preset,Remote CMS, Front LED |
|||
| Input / Output | 4/1 - NC/NO | |||
| Display | HDMI | Full HD, XGA | ||
| VGA | Full HD, XGA | |||
| TV | SDTV(720x480/576) | |||
| Mode | 16/9/4/1/SEQ/BIG - LIVE, 16/9/4/1 - P.B | |||
| Camera Title Name | English : 20 characters, Chinese, Japanese, Korean : 10 characters | |||
| External Interface |
PTZ / Keyboard | 2 RS485 - Terminal Block | ||
| ATM/POS | RS232C - Terminal Block, Ethernet POS | |||
| Storage | Primary/External | 2 HDD or 1 HDD + 1 eSATA | ||
| Features | Universal | Yes | ||
| EOL | Yes | |||
| Digital Zoom | x1 ~ x16 | |||
| Watermarking | Yes | |||
| Detection / Search | Motion, Sensor, Audio, Text | |||
| Fan Fail | Yes | |||
| 5 Users | ||||
| Capture | Full HD, XGA | |||
| DDNS, DHCP, UPNP | Yes | |||
| CMS, VMS, RMS | Windows | |||
| Smart Phone (3G) | Android, iPhone, iPad | |||
| Mac Viewer | Apple Mac OS | |||
| Genaral | Power Supply |
16,8ch: 12V/5A - Level 5 4ch: 12V/3.3A |
||
| Consumption |
16,8ch: 60Watts 4ch: 40 Watts |
|||
| Operating Temp. | 5 ~ 40˚C | |||
| Humidity | 10 ~ 80% | |||
| Weight w/o HDD | 3Kg | |||
| Dimension | 340 x 59 x 300 mm | |||
| Certification | HDcctv, CE, FCC, RoHS Compliance | |||
 |
 |
 |
 |
 |
 |
 |
