DVR Digital Video Recorders
VIEW
Features
    - 6 HDD Bays
  • - Backup
  • - Digital Zoom
  • - DDNS, DHCP, UPnP
  • - Multi-Language Supported
  • - Privacy Zone
  • - Covert Channel
  • - Two-way Audio
Distinctive Features
  • - Dual 485 Port
  • - Coaxitron
  • - POS
  • - eSATA
  • - P2P
General
  • - OS: Embedded Linux
  • - Compression: H.264
  • - Power Supply: 90~250V, 50/60Hz
  • - Consumption: 80Watts
  • - Operating Temp: 5~40°C
  • - Humidity: 10 ~ 80%
  • - Net Weight (w/o HDD): 8kg
  • - Certification: CE, FCC, RoHS Compliance
Network Software
  • · VMS, RMS
    · Smartphone Viewer : Smart Eyes Pro
  • · Mac Viewer
Dimensions
  • · Size - 440 x 88 x 430mm
5brid (TVI, CVI, AHD, 960H, IP)
Line Up 5brid
Series Deluxe
Model No. HD6-532 HD6-516
System OS Embedded Linux
Language Chinese, Chinese(S), Dutch, English, French, German, Hebrew, Hungari, Italian, Japanese, Korean, Latvian, Persian, Polish, Portuguese, Russian, Spanish, Sweden, Turkish, Arabic
Time Accuracy 5ppm (12.5sec/month)
Time Sync. NTP, GMT, DST, Time Server
User 15 Users (Admin., User1 ~ User14)
Camera IP Camera ONVIF Profile S
Video System NTSC / PAL
Input 32 BNC / 16 BNC
IPC Input 16 IPC / 8 IPC
Output Interface HDMI, VGA, BNC
Spot HD-TVI spot, SD spot
Audio Input Interface 16 RCA
Output Interface 1 HDMI, 1 RCA
Video
Recording		 Compression H.264
Speed 15fps/ch, 30fps/ch
Resolution TVI(720p, 1080p, 3MP, 4MP, 5MP, 4K), AHD(720p,1080p, 3MP), CVI(720p, 1080p),  Analog SD(960H), IP(Max. 4MP)
Quality 5 Levels
Audeo
Recording		 Compression G.711u
Playbacka Search Go to first rec. time, Go to last rec. time,
Go to last search time,
Calendar, Log viewer, Smart search,
Multi-time & day search, Event search
Mode Event only playback, Backward,
Pause, Frame by frame, Speed up (x1 ~ x32, x300)
Network Interface RJ45 (Ethernet 10/100/1G) x 2
Compression H.264
Speed Max. 1080p 15fps/ch
Resolution Max. 2MP(1080p)
Backup Interface USB, Network
Format RMS, AVI
Alarm Post-Alarm 5sec~5min
Motion Grid
32 x 24
Alarm Action E-mail, Event Popup, Buzzer, Relay,
PTZ Preset,Remote VMS, Front LED
Input / Output 16/4 - NC/NO
Display HDMI Full HD, XGA
TV SDTV(720x480)
Mode

32/16/9/4/1/SEQ/BIG - LIVE, 32/16/9/4/1 - P.B

16/9/4/1/SEQ/BIG - LIVE, 16/9/4/1 - P.B
External
Interface		 PTZ / Keyboard 2 RS485 - Terminal Block
ATM / POS RS232C - Terminal Block, Ethernet POS
Storage Primary 6 HDD
External 2 eSATA
Genaral Power Supply 90~250V, 50/60Hz
Consumption 80W
Operating Temp. 5 ~ 40˚C
Humidity 10 ~ 80%
Weight w/o HDD 8Kg
Dimension 440 x 88 x 430 mm
Certification CE, FCC, RoHS Compliance
