HOME > PRODUCT > Digital Video Recorders > 5brid DVR > Lite-C series
| Line Up | 5brid-C | ||
|---|---|---|---|
| Series | Lite-C | ||
| Model No. | MT6-516 | MT6-508 | |
| System | OS | Embedded Linux | |
| Language |
Chinese, Chinese(S), Dutch, English, French, German, Hebrew, Hungari, Italian, Japanese, Korean, Latvian, Persian, Polish, Portuguese, Russian, Spanish, Sweden, Turkish, Arabic |
||
| Time Sync. | NTP, GMT, DST | ||
| User | 15 Users (Admin., User1 ~ User14) | ||
| Camera | IP Camera | ONVIF Profile S | |
| Video | Input | 16 BNC / 8 BNC | |
| Output | HDMI, VGA | ||
| Audio | Input | 16 RCA / 8 RCA | |
| Output | 1 HDMI, 1 RCA | ||
| Video Recording |
Speed | Max. 15fps/ch | |
| Resolution |
TVI(720p, 1080p, 3MP, 4MP, 4K), AHD(720p, 1080p) CVI(720p, 1080p), Analog SD(960H), IP(Max. 4MP) |
||
| Mode | Auto, Continuous, Event | ||
| Event | Motion, Audio | ||
| Bit Rate | 512Kbps ~ 3Mbps/Ch, Adjustable | ||
| Quality | 5 Levels | ||
| Audeo Recording |
Compression | G.711u | |
| Audio Sampling Rate | 8KHz | ||
| Audio Bit Rate | 32Kbps | ||
| Network | Interface | 1 X Ethernet 10/100/1G | |
| Compression | H.264 | ||
| Speed | Max. 1080p 15fps/ch | ||
| Resolution | Max. 2MP(1080p) | ||
| Backup | Interface | USB, Network | |
| Format |
Video Clip, (Backup viewer), JPEG still image, Log list, Setup data |
||
| Alarm | Post-Alarm | 5sec~5min | |
| Motion Grid | 32 x 24 | ||
| Alarm Action | E-mail, Event Popup, Buzzer, Relay, PTZ Preset,Remote VMS, Front LED |
||
| Input / Output | 4/1 | ||
| Display | HDMI / VGA | Full HD, XGA | |
| TV | SDTV(720x480) | ||
| External Interface |
PTZ / Keyboard | RS485 - Terminal Block | |
| Storage | Primary | 2 HDD (Max. 6TB) | |
| Genaral | Power Supply | 12V / 2A | |
| Consumption | 12V / 2A | ||
| Operating Temp. | 5 ~ 40˚C | ||
| Humidity | 10 ~ 80% | ||
| Weight w/o HDD | 3Kg | ||
| Dimension | 378x340x50mm | ||
| Certification | CE, FCC, RoHS Compliance | ||
 |
 |
 |
 |
 |
 |
 |
